Slingshot One-Lock Glide Front Wing

LIFT / GLIDE / CARVE

The Slingshot One-Lock Glide Front Wing is the most efficient front wing in the One-Lock line.

Design Details:

THE DESIGN DIFFERENCE:
Through utilizing a medium-high aspect ratio, we found the most forgiving and playful front wing shape yet. The medium high camber profile excells in low end lift, allowing smaller wings to get up at slower speeds. When accelerating to faster speeds, the wing tip twist prevents the foil from gaining lift. This means there is no increase in front foot pressure when pushing the foil to the extremes.

WHO IT’S FOR:
The Glide line of front wings is designed for riders seeking the best all-around wing for their second foil purchase. With a balance of lift, maneuverability, and consistent foot pressure, this wing allows riders to quickly adapt and gain confidence. The trust built in the foil’s feel accelerates progression, enabling riders to ride faster and with greater control.

Package Includes:
One-Lock Glide Front Wing, Protective Cover, Replacement One-lock Latch kit

MEDIUM-HIGH CAMBER PROFILE:
A Medium-High Camber Profile was used on this front wing to boost low-end lift in a compact surface area. This design allows the rider to use a smaller wing, resulting in a more nimble and agile foil that’s still easy to control across a wide range of wind conditions.

SLINGSHOT STIFF CONSTRUCTION:
The Glide front wing series is constructed with a blend of high and mid modulus carbon, creating a stiff, high-performance wing. The carbon layers are strategically positioned at 0° along the span to maximize stiffness and at 45° to prevent wing twist. Additionally, an internal stringer has been incorporated to further enhance the wing’s stiffness.

Specs:

Features:

• One-Lock™ Latch - Our front wings come with a preinstalled One-Lock™ latch to secure the front and rear wings inside the collar on the bottom of the mast. Each wing includes an additional replacement OneLock™ latch.
• Fillets - Our wings incorporate fillets to increase their overall strength. These fillets also help minimize drag, resulting in a more efficient performance.
• Slingshot Stiff Construction - The wings are constructed with a blend of high and mid modulus carbon, creating a stiff, high-performance wing. The carbon layers are strategically positioned at 0° along the span to maximize stiffness and at 45° to prevent wing twist. Additionally, an internal stringer has been incorporated to further enhance the wing’s stiffness.
• Monobloc Front Wing - The front part of our fuselage section is now molded into the front wing using a Carbon Arc Layup, reducing drag and creating a stronger connection for increased responsiveness. The construction of the fuselage section is consistent across the One-Lock line, further ensuring reliable control and performance while enhancing the direct feedback from the front wing.
• Hand Finished - All of our front wings are hand-finished to precisely tune the flow of water off the trailing edge and tips. This meticulous process results in a more efficient foil and a smoother ride on the water.
• Forgiving Medium Camber Profile - Our Kite 1255 Front Wing features a forgiving medium camber profile with maximum thickness and camber positioned far forward. This design results in a very low stall speed, making the wing more forgiving and easier to ride.
• High Speed Profile - Our Kite 755 features a high-speed profile that keeps the front wing loose in the water. Whether at high or low speeds, the 755 responds quickly and avoids the lockout effect common in other front wings.
• Medium-High Speed Profile - Our Kite 855 features a medium-high-speed profile that keeps the front wing loose in the water. Whether at high or low speeds, the 855 responds quickly and avoids the lockout effect often seen in other front wings.
