Description
The ultimate wave riding foil. The overall shape of the foil offers the optimum balance between glide, manoeuvrability and control. Work the slightest wave with surgical precision and pump up to the peak effortlessly.
Specs:
Front wing monobloc
| Surface (cm2) | Span (mm) | Aspect Ratio | Cord max (mm) | Thickness max (mm) | Fuselage size (cm) | Construction | Weight (kg) | Screw size |
|---|---|---|---|---|---|---|---|---|
| 650 | 720 | 8 | 115 | 13.7 | 57.2 | UHM Carbon | 0.95 | – |
| 850 | 824 | 8 | 134 | 16 | 55.5 | UHM Carbon | 0.96 | – |
| 1050 | 916 | 8 | 150 | 17.9 | 53.8 | UHM Carbon | 1.0 | – |
Stabilizer
| Surface (cm2) | Span (mm) | Aspect Ratio | Cord max (mm) | Thickness max (mm) | Construction | Weight (kg) | Screw size | Compatibility |
|---|---|---|---|---|---|---|---|---|
| 132 | 300 | 6.8 | 58.8 | 7.1 | UHM Carbon | 0.1 | 12 | Silk 650 |
| 142 | 320 | 7.2 | 58 | 7 | UHM Carbon | 0.1 | Silk 850 | |
| 152 | 340 | 7.6 | 57.3 | 6.9 | UHM Carbon | 0.1 | Silk 1050 |
HR Carbon Mast
| Length (cm) | Cord min (mm) | Thickness min (mm) | Screw size (male/fuselage) | Construction | Weight (kg) |
|---|---|---|---|---|---|
| 80 | 135 | 16 | M8x40mm | HR Carbon | 1.6 |
HM Carbon Mast:
| Length (cm) | Cord min (mm) | Thickness min (mm) | Screw size (male/fuselage) | Construction | Weight (kg) |
|---|---|---|---|---|---|
| 80 | 120 | 15 | M8x40mm | HM Carbon | 1.9 |
| 85 | 120 | 15 | M8x40mm | HM Carbon | 2 |
UHM Carbon Mast
| Length (cm) | Cord min (mm) | Thickness min (mm) | Screw size (male/fuselage) | Construction | Weight (kg) |
|---|---|---|---|---|---|
| 75 | 100 | 12.8 | M8x40mm | UHM Carbon | 1.5 |
| 80 | 115 | 13.8 | M8x40mm | UHM Carbon | 2 |
| 85 | 115 | 13.5 | M8x40mm | UHM Carbon | 2.3 |
| 95 | 120 | 12.3 | M8x40mm | UHM Carbon | 2.3 |
Features:
- Bumpy foil
- Adaptive design
- Monobloc structure
Program:
Wing foil waveriding / Surf foil / Sup foil / Downwind
Includes:
Screws, cover, case
Additional Information
Model: |
2024 |
Sizes: |
650 / 850 / 1050 |
Construction: |
UHM Carbon |
Riding Style: |
Wing foil waveriding / Surf foil / Sup foil / Downwind |
