Description
2021 North Sonar Carbon Foil
**Front Wings sold separately**
Included: CF72 or CF85 Mast, C600 Fuselage, S01 Stabilizer with cover, Tool Kit, Screw Packs B,C,* Travel Bag.
What North has to say about the Sonar Carbon Foil
Insane response. Incredible performance. Our new highest quality pre-preg carbon modular foil edition provides a stiffer, more direct feel and more immediate feedback.
Engineered with increased strength for higher loads, the Carbon Edition excels across all foiling disciplines. The refined one-piece mast design is tapered for optimal load transfer and lower surface friction, and features our unique GeoLock system.
Comes complete with our new high-strength 600m pre-preg carbon fuselage and S01 Stabilizer for a durable, corrosion-free foil with great pumpability and a sporty feel with earlier take-offs. The CF72 mast is ideal for shallower waters, and prone surf foiling. The longer CF85 mast increases overall ride performance in choppy conditions.
*Foil to board mounting screws are included with North Foil Boards.
Recommended Mast and Wing Setup
Kite | Wing | Wing (Jumps) | Surf | SUP | Tow-Surf | Wake | |
SONAR CF72 MAST / CARBON FOIL EDITION |
850 / 1150 / 1500R / 1850R |
HA1250 / HA1450 / 1500R / 1650 / 1850R / 2200R |
HA1250 / HA1450 / 1500R / 1650 / 1850R |
HA1250 / HA1450 / 1500R / 1650 / 1850R / 2200R |
1500R / 1650 / 1850R / 2200R |
850 / 1150 / 1500R | 850 / 1150 / 1500R / 1650 / 1850R / 2200R |
SONAR CF85 MAST / |
850 / 1150 / 1500R | HA1250 / HA1450 / 1500R / 1650 / 1850R / 2200R |
HA1250 / HA1450 / 1500R / 1650 / 1850R |
- | 1650 / 1850 / 2200R | 850 / 1150 / 1500R | 850 / 1150 / 1500R / 1650 / 1850R / 2200R |
2021 Design
- Front wings sold separately
- New lightweight pre-preg carbon one-piece mast (CF72 or CF85)
- C600 pre-preg carbon fuselage weighs ~50% less than the A600
- Carbon pre-preg stabilizer
- GeoLock connection joins the mast and
- fuselage, so they feel like one piece
- Easy recovery from surface breaching
- Fits all boards with 165x90mm mounting pattern
Features
- Sonar CF72 or CF85 Mast
- GeoLock Load Bearing Connection
- Easy recovery from surface breaching
- Industry-standard 165x90mm bolt pattern
- Carbon Fuselage 600mm
- Modular foil system
- Supplied with Sonar Travel Bag
- Foil to board mounting hardware supplied with North Foil Boards
- Front wings sold separately
North Foil Hardware Guide
Connection | Model | Head | Qty and Length | Diameter |
---|---|---|---|---|
Board Adaptor to Board | Recessed Star | 4 x 30mm | M8 | |
Board Adaptor to Mast (A) | Recessed Star | 2 x 40mm | M8 | |
Alloy Fuselage to Mast (B) | Star Socket | 2 x 35mm | M8 | |
Carbon Fuselage to Mast (B2) | Recessed Star | 2 x 30mm | M8 | |
Fuselage to Stabilizer (C) | Recessed Star | 2 x 16mm | M8 | |
Front Wing to Fuselage (D-I) | MA v2 700 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 850 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 1050 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 1200 | Recessed Star | 3 x 30mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 1500 | Recessed Star | 3 x 33mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 1850 | Recessed Star | 3 x 35mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 2100 | Recessed Star | 3 x 35mm | M8 |
Front Wing to Fuselage (D-I) | MA v2 2400 | Recessed Star | 3 x 40mm | M8 |
Front Wing to Fuselage (D-I) | SF 580 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | SF 680 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | SF 830 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | SF 930 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | SF 1080 | Recessed Star | 3 x 30mm | M8 |
Front Wing to Fuselage (D-I) | SF 1230 | Recessed Star | 3 x 30mm | M8 |
Front Wing to Fuselage (D-I) | HA 550 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | HA 650 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | HA 750 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | HA 850 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | HA 950 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | HA 1050 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | HA 1150 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | HA 1250 | Recessed Star | 3 x 30mm | M8 |
Front Wing to Fuselage (D-I) | HA 1450 | Recessed Star | 3 x 30mm | M8 |
Front Wing to Fuselage (D-I) | Pump 1800 | Recessed Star | 3 x 33mm | M8 |
Front Wing to Fuselage (D-I) | Pump 2050 | Recessed Star | 3 x 33mm | M8 |
Front Wing to Fuselage (D-I) | DW 750 | Recessed Star | 3 x 23mm | M8 |
Front Wing to Fuselage (D-I) | DW 900 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | DW 1100 | Recessed Star | 3 x 25mm | M8 |
Front Wing to Fuselage (D-I) | DW 1400 | Recessed Star | 3 x 30mm | M8 |
